Technical Specification

Rated voltage

40.5

Rated insulation

Power frequency withstand voltage

Dry

kV

95

Wet

80

level

Lightning impulse withstand voltage (peak)

185

Rated current

A

1250、1600、2000

Rated short-circuit breaking current

kA

20、25、31.5

Rated operation sequence

Points -0.3s combined -180s combined

Rated short circuit current breaking times

Times

≥30

Rated short circuit closing current (peak)

kA

50、63、80

Rated peak withstand current

Rated short-time withstand current

kA

20、25、31.5

Rated short circuit continuous current

S

4

Average opening speed

m/s

1.5±0.2

Average closing speed

0.7±0.2

Contact closing bounce time

≤2

Three-phase combined (minute) gate synchronous time difference

S

≤2

Closing time

≤150

Opening time

≤60

Mechanical life

Times

10000

Rated operating voltage and auxiliary circuit rated voltage

V

DC220、110、24

AC220、110、24

DC resistance per phase circuit (without transformer)

μΩ

≤100

Dynamic and static contacts allow wear thickness

mm

3

Weight

kg

800
